Custom transformers & substations · European and international projects

The exact transformer your project needs.

Custom transformers and integrated MV substations, specified for your project, with technical follow-up, testing and delivery under the agreed scope.

CEIEC / EN projects50 / 60 Hz project-specific
15–18 wksIndicative distribution target; written confirmation by configuration and destination
100 %Routine tests before dispatch; witnessing to be agreed for the project
1One single contact, from quotation to delivery
24 monthsContractual warranty, handled directly, no intermediary
Quick enquiry

Start with the essentials

Tell us the product, approximate rating and your e-mail. We will review the requirement and identify any missing information. For voltages, delivery country and project details, use the full configurator.

Destination and project stage (optional)

Have a drawing or specification?

Send the single-line diagram, specification or nameplate with the destination and quotation deadline. Attach the files in your e-mail.

Send drawings / specification
Replacement / retrofit

A transformer that failed or is at end of life? That's our ground

Failure, repeated summer tripping, an obsolete unit or a load that has grown : give us the rating plate and the room constraints, and we return an equivalent or better-sized unit, Tier 2 compliant, delivery to site quoted, with a single contact. Indicative 15–18 week lead time.

Indicative 15–18 wk lead timeMatches the room dimensionsCE / Tier 2 compliantDelivery to site quotedSingle Veltrium contact

See replacement / retrofit →
Lead time

A schedule confirmed for your project

Indicative target of 15 to 18 weeks for standard distribution configurations, confirmed for the equipment and destination. The offer states the schedule and its starting conditions, after deposit and technical approval.

Technical approval

Specification, drawings and deposit establish the start date.

Production and tests

The inspection programme and any witness tests are agreed before manufacturing.

Delivery and site interfaces

The offer states transport, import, unloading and any local contractor services.

Read the lead-time guide →

Configurator · custom quotation

Describe your transformer, receive a firm quotation

Type, power, voltages, vector group, cooling… configure your unit in a few minutes. No automatic pricing : every transformer is custom-built. First reply within 48 h, quotation generally within 5 working days for standard projects with complete data.

Configure my quote →
Product range

Custom-built, not catalogue

European transformer and substation ranges, plus a project-specific 60 Hz line for the United States. See the full range →

Distribution transformer range: 250–3,150 kVA. Higher ratings and integrated substations are reviewed to your project specification.

Transformers
Substations
RangeTechnologyPowerVoltageTypical use
Oil-immersed distributionMineral oil / ester250 – 3,150 kVA≤ 36 kVGrids, industry, outdoor substations
Cast resin (dry)Dry, indoor250 – 3,150 kVA≤ 36 kVData centers, public buildings, sensitive sites
MV substationPackaged, prefabricated (IEC 62271-202)per transformer≤ 36 kVGrid connection, industrial sites
Skid substationContainerised / e-house (IEC 61439 + 62271-200)per transformer≤ 36 kVBESS, solar farms, EV hubs, temporary power
HV substationEngineered-to-orderup to ~100 MVA36 – 170 kVRenewables evacuation, large sites
US pad-mounted transformerCompartmentalized, 60 HzProject-specificPer utility specificationUS distribution, commercial and industrial projects

Typical range, indicative values

Oil-immersed ONAN, 20 kV → 400 / 230 V, losses compliant with Ecodesign Tier 2 (EU 548/2014). Exact guaranteed losses, mass and dimensions are confirmed with the quotation.

PowerTypical UccIndicative mass
400 kVA4 %≈ 1.3 t
630 kVA4 %≈ 1.8 t
1,000 kVA6 %≈ 2.6 t
1,600 kVA6 %≈ 3.7 t
2,500 kVA6 %≈ 5.2 t
Parts & accessories · no commitment

Start with a part, not a whole project

You don't need a full transformer to work with us. A bushing, a DGPT2 relay, a set of gaskets for your existing fleet, any brand: identified from a reference or a nameplate photo, quoted and delivered fast. It's the easiest way to try us, same rigour, same single contact, reply within 48 h.

Any brandFrom a reference or nameplate photoBushingsDGPT2 & BuchholzGaskets & valves48 h reply

Explore spare parts →
Cast resin · dry type

Dry-type transformers for indoor installations

No flammable liquid, indoor installation, lighter maintenance: the dry-type transformer has become the default choice for data centers, public buildings and sensitive sites across France and the EU. We supply it bare or inside an IP-rated metal enclosure. See the cast-resin range →

Cast resin dry-type transformer inside its metal enclosure, cover open
Dry-type transformer being lifted onto its test bench
Sectors

Solutions for your application

Data centers & IT (K-rated designs for non-linear loads) · Solar and wind (step-up units, bidirectional flow, evacuation substations) · Battery storage and EV charging hubs · Industry and grid operators. Each sector has its constraints, we design for them, not around them.

Warranty & after-sales

24-month warranty and project support

24-month contractual warranty against material and workmanship defects. The start date, conditions and any extension are specified in the accepted offer. One point of contact answers your requests within 48 h.

24-month warrantyExtension availableDelivery to site quotedSingle Veltrium contactParts available48 h reply

See warranty & after-sales →
EU compliance

Compliance and technical documentation

Placing a transformer on the EU market carries clear obligations, and as the brand, we carry the manufacturer's obligations: CE marking, technical file, EU Declaration of Conformity, Tier 2. For the import itself, either your company acts as importer of record (we supply the complete documentation pack) or we arrange delivery through an EU-established importer.

CE marking

EU Declaration of Conformity and full technical file, under our manufacturer responsibility.

Ecodesign Tier 2

Regulation (EU) 548/2014: capped losses, mandatory since July 2021. Verified at the factory.

IEC / EN 60076

Type, routine and special tests; third-party witnessing subject to an agreed scope.

RoHS / REACH

Hazardous substances controlled and documented across all components.

WEEE

Producer registration and eco-contribution handled, mandatory from the very first unit.

For projects in France, the applicable NF standards and DSO requirements are agreed with the project team. Technical guides and project documents are available in French and English.

Why Veltrium Énergie

Technical project support, from quotation to delivery

  • 01
    One point of contact for your projectWe define the specification, coordinate quality control and follow the agreed milestones through to delivery.
  • Project compliance: the quotation identifies applicable product requirements, technical evidence and responsibilities before the order.
  • 02
    Factory cost, European rigourSpecification, materials and the inspection programme defined in your offer, with test reports reviewed before dispatch.
  • 03
    One contact, two worldsBased on the production side, replying in English and French, from quotation to delivery.
50 Hz
European reference range designed natively for 50 Hz; US projects are specified separately at 60 Hz

Dyn11
Standard EU distribution vector group by default

Every quotation starts from your real specs. No rebadged generic product.

Project essentials

From an initial enquiry to a defined supply scope

Technical inputs

630, 1,000 or 1,600 kVA: start with the voltage ratio, installation constraints and delivery location. Review the product ranges →

Documents and inspection

See the existing workshop photographs, the planned document milestones and an illustrative report structure. Review the technical dossier →

Delivery scope

Equipment, site cables, lifting, installation and commissioning are defined separately in the quotation, with a written schedule.

Project essentials

Specify the destination from the start

France and the EU

Send the applicable project standards, network operator requirements, required documents and import arrangement.

United Kingdom

Send the DNO specification, network voltages, 50 Hz duty, loss requirements and installation interfaces. Applicable conformity and import requirements are confirmed for the project.

United States

Use the dedicated 60 Hz page for pad-mounted and compartmentalized designs, utility requirements and project-specific tests.

Ready to quote

Send us your specs. We send you a firm price.

Configure in a few minutes, or simply e-mail your own technical specification. First reply within 48 h; quotation generally within 5 working days for standard projects with complete data.

Request a quotation →
